AEOLUS Line
Special series with variable inclination.
DATA SHEET
It is the ideal solution for TUNNEL VENTILATION – CROSS VENTILATION on farms and wherever longitudinal or transverse ventilation is desired. Excellent for creating a good microclimate which is the essential condition for ensuring an optimal level of COW COMFORT (so directly related to the health and well-being of the animal). It is also essential to maintain sustainable farming and control the problem of HOT STRESS.
This solution is perfectly combined with the wetting system.
The machines can be tilted at will from 0 to 90 ° (or work horizontally for particular applications).
The fans are fitted with a permanent magnet motor for maximum energy efficiency with an IP65 protection degree, maintenance free and complete with a compact IP65 inverter with fast connections guaranteed by the PLUG & PLAY solutions.
It is possible to modify performance based on customer requests through the use of software that allows you to select the optimal solution.
MODEL
AEOLUS 2500
Impeller diameter 2,5mt. - 3 blades
MODEL
AEOLUS 1800
Impeller diameter 1,8mt. - 3 blades
Ring conveyor accessories to direct the air flow
MODEL
AEOLUS 1300
Impeller diameter 1,3mt. - 3 blades
Ring conveyor accessories to direct the air flow
MODEL
AEOLUS 1300
Impeller diameter 1,3mt. - 4 blades
Ring conveyor accessories to direct the air flow
ACCESSORIES
POTENTIOMETER
PMR-L20 + Temp. probe
PMR-L23THI + Temp. probe
PMR-G2020 THI + Temp. probe
Anemometer
